The series FP polypropylene self-priming anti-corrosion centrifugal pump is a new modified a plastic chemical pump which is developed on the basis of absorbing domestic and international advanced technology of the same product. It adopts mechanical seal and use CFR-PP (enhanced polypropylene as the material of pump body).
It is just need to add the amount of liquid in the pumps for self-priming before starting pump.
Features
1: Unique structure,
2: High corrosion resistance
3: Easy operation and no leakage
4: Light weight, small volume, long lift
Applications
1) Chemical industry (Acid, alkali, hydrochloric acid etc corrosive liquid)
2) Food stuff, pharmacy, electroplate, papermaking
3) Environment protection, water treatment etc
4) Metallurgical, sewage dealing and etc.
Technical Data
1. Flow Rate (Q): 3～50m3/h
2. Rotary speed (n): 2900r/min
3. Total Lift Head (H): 7～32m
4. Inlet diameter: 20～80mm
5. Outlet diameter: 15～65mm.
6. Power: 0.37～7.5kw
Parameter Table
|
MODEL |
CALIBER |
CAPACITY |
HEAD |
SUCTION DISTANCE |
SPEED |
VOLTAGE |
MOTOR POWER |
|
Inlet |
Outlet |
m3/h |
m |
m |
r/min |
V |
KW |
|
FP20-15-100(105) |
20 |
15 |
3 |
7 |
4 |
2900 |
380 |
0.37 |
|
FP32-25-100(104) |
32 |
25 |
4 |
7 |
6.5 |
220 |
0.55 |
|
FP32-25-105(103) |
32 |
25 |
6.3 |
8 |
6.5 |
380 |
0.75 |
|
FP40-32-125(102) |
40 |
32 |
12.5 |
20 |
6.5 |
380 |
1.5 |
|
FP50-40-130(101.5) |
50 |
40 |
13 |
22 |
6.5 |
380 |
2.2 |
|
FP65-50-150(101) |
65 |
50 |
25 |
25 |
6 |
380 |
4 |
|
50FP-22 |
50 |
40 |
13 |
22 |
6 |
380 |
2.2 |
|
65FP-25 |
65 |
50 |
20 |
25 |
6 |
380 |
4 |
|
80FP-28 |
80 |
65 |
50 |
28 |
4 |
380 |
5.5 |
|
80FP-32 |
80 |
65 |
50 |
32 |
4 |
380 |
7.5 |
