FPZ Anti-Corrosion Plastic Self-priming Chemical Pump
FPZ anti-corrosion plastic self-priming chemical pump adopts reinforced polypropylene (PP) one-time injecting mould. With high mechanical strength and strong corrosion resistance performance, self-priming pump structure has unique scientificalness, inside pump chamber there are imbibitions chamber, storage room, back liquid check valve, gas-liquid separation chamber, reflow hole. Only perfuse fluid before the first starting, and do not need to repeat from now on, when suction medium.
Liquid can be intermittence, break liquid can continue to suction within 15 minutes coming liquid, mechanical seal is not need for additional cooling water cooling, operation is simple and safe without leakage, is the best product that replaces submerged pump.
Features
1: compacted structure, high efficiency
2: Close and long coupling way
3: Small Vibration, Low Noise
4: Strong self-priming, Good Performance
Applications
1) Enduring common acid, alkali and salt.
2) Petrochemical, pharmacy
3) Food, smelt, environment protects sewage treatment and salt fields
Technical Data
1. Flow Rate (Q): 2.5～100m3/h
2. Rotary speed (n): 2900r/min
3. Total Lift Head (H): 10～32m
4. Inlet diameter: 25～100mm
5. Outlet diameter: 20～80mm.
6. Power: 0.55～11kw
Parameter Table：
|
Model |
Inlet x outlet
(mm) |
Flow
(m3/h) |
Head
(m) |
Rotary Speed (r/min) |
Suction Height
(m) |
Motor Power
(kw) |
|
25FPZ-10(D) |
25×20 |
2.5 |
10 |
2900 |
5 |
0.55 |
|
32FPZ-11(D) |
32×25 |
3.4 |
11 |
2900 |
5 |
0.75 |
|
40FPZ-18 |
40×32 |
11 |
18 |
2900 |
5 |
1.5 |
|
50FPZ-20 |
50×40 |
13 |
20 |
2900 |
5 |
2.2 |
|
65FPZ-25 |
65×50 |
26 |
25 |
2900 |
5 |
4 |
|
80FPZ-32 |
80×65 |
50 |
32 |
2900 |
5 |
7.5 |
|
100FPZ-40 |
100×80 |
100 |
20 |
2900 |
5 |
11 | |
